SI8274GB1-IMR

Product Category : Gate Drivers

Rise / Fall Time (Typ) : 10.5ns, 13.3ns

Voltage - Supply : 4.2 V ~ 30 V

Mounting Type : Surface Mount

Current - DC Forward (If) (Max) : -

Manufacturer : Silicon Labs

Minimum Quantity : 2500

Operating Temperature : -40°C ~ 125°C

Current - Peak Output : 4A

Common Mode Transient Immunity (Min) : 150kV/µs

Voltage - Isolation : 2500Vrms

Supplier Device Package : 14-LGA (5x5)

Pulse Width Distortion (Max) : 19ns

Part Status : Not For New Designs

Current - Output High, Low : 1.8A, 4A

Packaging : Tape & Reel (TR)

Number of Channels : 2

Voltage - Forward (Vf) (Typ) : -

Propagation Delay tpLH / tpHL (Max) : 75ns, 60ns

Package / Case : 14-VFLGA

Technology : Capacitive Coupling

Approvals : CQC, CSA, UR, VDE

Series : Automotive, AEC-Q100

Description : DGTL ISO 2.5KV GATE DRVR 14LGA
