ACPL-W349-060E

Product Category : Gate Drivers

Rise / Fall Time (Typ) : 8ns, 8ns

Voltage - Supply : 15 V ~ 30 V

Mounting Type : Surface Mount

Current - DC Forward (If) (Max) : 25mA

Manufacturer : Broadcom Limited

Minimum Quantity : 1700

Operating Temperature : -40°C ~ 105°C

Current - Peak Output : 2.5A

Common Mode Transient Immunity (Min) : 100kV/µs

Voltage - Isolation : 5000Vrms

Supplier Device Package : 6-SO

Pulse Width Distortion (Max) : 40ns

Part Status : Active

Current - Output High, Low : 2A, 2A

Packaging : Bulk

Number of Channels : 1

Voltage - Forward (Vf) (Typ) : 1.55V

Propagation Delay tpLH / tpHL (Max) : 110ns, 110ns

Package / Case : 6-SOIC (0.268", 6.80mm Width)

Technology : Optical Coupling

Approvals : CSA, IEC/EN/DIN, UR

Series : -

Description : OPTOISO 5KV 1CH GATE DRIVER 6SO
